Description
The Macromatic VWKE120A is a compact, 17.5 mm modular voltage band monitoring relay designed to protect sensitive single-phase electrical equipment operating on a 120 VAC nominal power supply. By continuously checking input voltage levels, the VWKE120A ensures connected machinery remains energized only when the voltage stays within user-defined upper and lower limits, dropping out if overvoltage or undervoltage conditions occur.
Featuring front-panel adjustment dials for setting overvoltage (80–150 VAC) and undervoltage (30–95% of the overvoltage setting), this 35mm DIN rail-mounted relay includes an adjustable drop-out time delay (0.1 to 10 seconds) to prevent nuisance tripping from momentary voltage transients. Equipped with a high-capacity 15A SPDT output contact, silver alloy contacts, and clear dual LED indicators (Green for voltage present, Red for relay energized), the VWKE120A provides reliable power protection for industrial control panels, motors, and automation systems.
Key Features
- Voltage Band Protection: Continuously monitors 120 VAC single-phase power to keep equipment operating strictly within set upper and lower voltage limits.
- Adjustable Voltage Dials: Independent front-panel dials configure overvoltage from 80–150 VAC and undervoltage from 30–95% of the selected overvoltage limit.
- Adjustable Drop-Out Time Delay: Programmable 0.1 to 10-second delay ignores brief voltage fluctuations to eliminate false shutdowns.
- High-Capacity 15A SPDT Output: Rated for 15 A @ 240 VAC/DC (B300 pilot duty) with durable silver alloy contacts for high-reliability switching.
- Ultra-Compact 17.5 mm Housing: Space-saving 0.69 in (17.5 mm) modular design snaps directly onto standard 35mm DIN rail.
- Dual LED Indicators: Green LED signals input voltage presence; Red LED indicates active relay energized output status.
Specifications
| Technical Specification | Detail |
|---|---|
| Product Model | VWKE120A |
| Brand | Macromatic |
| Product Type | Voltage Band Monitoring Relay (Single-Phase AC) |
| Monitored Voltage | 120 VAC |
| Output Contact Configuration | 15A SPDT |
| Output Contact Rating | 15 A @ 240 VAC / 240 VDC, Pilot Duty B300 |
| Overvoltage Range | 80 to 150 VAC (Adjustable) |
| Undervoltage Range | 30% to 95% of Overvoltage setting (Adjustable) |
| Drop-Out Time Delay | 0.1 to 10 seconds (Adjustable) |
| Pick-Up Time Delay | 0.1 seconds (Fixed) |
| Repeatability | < 1% |
| Hysteresis | 2% to 6% |
| Minimum Switching Load | 100 mA @ 5 VDC / VAC |
| Contact Material | Silver Alloy |
| Power Burden | 3 VA |
| Mounting / Housing Width | 35mm DIN Rail Mount, 0.69 in (17.5 mm) width |
| Dimensions (H x W x D) | 3.55 in x 0.69 in x 2.52 in (90.2 mm x 17.5 mm x 64.0 mm) |
| Terminal Wiring Capacity | Up to 14 AWG (2.5 mm²) |
| Operating Temperature | -4°F to 131°F (-20°C to 55°C) |
| Storage Temperature | -22°F to 158°F (-30°C to 70°C) |
| Lifespan | Mechanical: 10,000,000 operations | Electrical: 70,000 operations |
| Standards & Approvals | UL Listed, CE |
| Primary Applications | Over/undervoltage equipment protection, HVAC control panels, motor power monitoring, sensitive electronics protection |
