Description
The ABB RT1P Thermal Overload Relay is a motor protection device designed for compatible ABB C-2000 IEC contactors and starters. Featuring an adjustable current range of 10 to 16 A, it helps protect motors against overload conditions by detecting excessive current and initiating a trip through the connected contactor control circuit.
Designed for industrial motor control applications, the RT1P supports Type 2 coordination when used with compatible C-2000 starters and the specified Class J fuse protection. This coordination helps ensure that, under short-circuit conditions, the starter assembly presents no danger to personnel or the installation and remains suitable for further use, subject to the manufacturer’s requirements.
The RT1P features a thermal overload protection mechanism with a Class 10 trip characteristic. Its contactor-mounted design and selectable manual or automatic reset options support integration into compatible motor starter assemblies, helping provide dependable motor protection in industrial equipment and electrical control panels.
Key Features
- Adjustable Current Range: Provides overload protection settings from 10 to 16 A to suit compatible motor applications.
- Thermal Overload Protection: Detects sustained excessive current and initiates a trip through the connected starter control circuit.
- Class 10 Trip Characteristic: Provides a Class 10 overload response for compatible motor protection applications.
- C-2000 Starter Compatibility: Designed for use with compatible ABB C-2000 IEC contactors and motor starters.
- Type 2 Coordination: Supports Type 2 coordination when used with the specified starter assembly and Class J fuses.
- Class J Fuse Coordination: Specifies LPJ-SP or AJT fuses with a maximum rating of 25 A for the documented coordination arrangement.
- Contactor Mounting: Installs directly onto a compatible contactor for integration into a motor starter assembly.
- Manual or Automatic Reset: Supports reset options according to the selected configuration and manufacturer’s instructions.
- Three-Pole Design: Provides thermal overload protection for compatible three-phase motor starter applications.
Specifications
| Technical Specification | Detail |
|---|---|
| Product Model | RT1P |
| Catalog Number | RT1P |
| Brand / Manufacturer | ABB |
| Product Type | Thermal Overload Relay |
| Product Family | C-2000 IEC Contactors and Starters |
| Adjustable Current Range | 10–16 A |
| Number of Poles | 3 |
| Trip Class | Class 10 |
| Mounting Type | Contactor Mounting |
| Reset Options | Manual or Automatic Reset, depending on configuration |
| Protection Function | Thermal Motor Overload Protection |
| Coordination Type | Type 2, with the specified compatible starter and fuse combination |
| Compatible Fuse Type | Class J |
| Specified Fuse Types | LPJ-SP or AJT |
| Maximum Fuse Rating for Specified Coordination | 25 A |
| Compatible Equipment | Compatible ABB C-2000 IEC Contactors and Starters |
| GO Schedule | C2 |
| UPC | 801701813711 |
