Description
The ABB CR-P024AC1 (Product ID: 1SVR405600R0000, EAN: 4013614498138) is a premium PCB-mountable and pluggable interface relay designed for signal isolation, amplification, and switching in industrial control systems. Operating on a 24 VAC control supply voltage, this compact pcb-style relay features 1 changeover (1 c/o / SPDT) output contact rated for switching loads up to 250 V / 16 A.
Engineered with an exceptional IP67 protection degree, the CR-P024AC1 offers complete sealing against dust, airborne particles, and water immersion up to one meter. It can be soldered directly onto printed circuit boards or combined with ABB’s standard or logical DIN rail sockets, retaining clips, and pluggable function modules to optimize cabinet space and simplify maintenance.
Key Features
- 24 VAC Control Voltage: Operates efficiently on standard 24 V AC control supply circuits.
- High-Capacity Output Contact: Features 1 c/o (SPDT) contact rated for 250 V / 16 A switching capacity.
- IP67 Sealed Enclosure: Provides complete ingress protection against dust, dirt, and water immersion up to 1 meter.
- Dual Mounting Versatility: Suitable for direct PCB mounting or tool-free insertion into DIN rail sockets.
- Space-Saving Interface Design: Compact footprint reduces overall panel space requirements when deployed on DIN rail sockets.
Specifications
| Technical Specification | Detail |
|---|---|
| Product Type / Model | CR-P024AC1 |
| Brand / Manufacturer | ABB |
| Product ID | 1SVR405600R0000 |
| EAN Code | 4013614498138 |
| Relay Type | Pluggable PCB / Interface Relay (CR-P Series) |
| Control Voltage (A1-A2) | 24 VAC |
| Output Contact Configuration | 1 c/o (SPDT – 1 Changeover Contact) |
| Contact Switching Rating | 250 VAC / 16 A |
| IP Ingress Protection Rating | IP67 |
| Mounting Option | PCB Direct Mount or Pluggable Socket Mount |
| Primary Applications | PLC I/O signal isolation, load switching, control panel automation, and PCB control boards |
