Description
Introducing the latest evolution in motor protection: the MTE SineWave Nexus® Filter. This advanced solution combines the high-performance filtering of a sinewave filter with MTE’s patented common mode protection technology into a single, passive device. The SineWave Nexus does more than just clean the PWM waveforms generated by Variable Frequency Drives (VFDs); it virtually eliminates the common mode voltage that leads to motor bearing failures. By addressing the electrical root cause of pitting, frosting, and fluting, it removes the need for high-maintenance shaft grounding rings or costly isolation transformers. It is the definitive electrical solution for an electrical problem.
Key Features
- Dual-action protection: Combines sinewave filtering with patented common mode reduction
- Eliminates motor bearing failures caused by harmful common mode voltages
- Prevents bearing damage such as pitting, frosting, and fluting
- Reduces motor noise and heating for significantly extended equipment life
- Eliminates the need for shaft grounding rings or isolation transformers
- Small package solution for easier integration into existing systems
- Three-year warranty for guaranteed performance and peace of mind
Specifications
- Product Series: SineWave Nexus® Filter
- Protection Type: Differential Mode (SineWave) + Common Mode Protection
- Maintenance Level: Zero (Passive device, no grounding rings to replace)
- Selection Criteria: Select based on Motor Full Load Amps (FLA)
- Warranty: 3 years
- Benefit: Optimal reduction of common mode/differential mode voltages and currents
Select your filter based on the Full Load Amps (FLA) of the motor. If the FLA is greater than the current rating of the filter, use the next larger size.
KMG16A01A
