Description
The MTE RLW-0P7506 reactor is specifically engineered to enhance the reliability and performance of industrial equipment by effectively mitigating power line disturbances and transient voltages. With an inductance of 61.000mH and a current rating of 0.75 amps, it provides robust protection and stability for 3-phase systems, ensuring smooth operation and extended equipment lifespan.
Features
- RoHS and REACH Compliant: Adheres to strict environmental and safety standards.
- Wide Voltage Range: Compatible with standard voltages ranging from 208 to 690 VAC, ensuring versatility across various applications.
- Amperage Flexibility: Available in ratings from 0.5 to 750 Amps, suitable for diverse power requirements.
- Transient Protection: Safeguards against voltage spikes and power fluctuations, enhancing equipment reliability.
- Epoxy Impregnation: Reduces audible noise, strengthens structural integrity, and improves resistance to moisture.
- Compact and Lightweight: Designed for space-efficient installation, facilitating ease of integration into machine building applications.
- Global Design: Engineered for international deployment, suitable for use in machines shipped worldwide.
- Optimized Performance: Delivers peak performance in a compact, lightweight design, surpassing standard reactor solutions.
- Suitability for Lower Horsepower: Ideal for protecting smaller motors and equipment from electrical disturbances.
- Certifications: CE and UL approved, ensuring compliance with global safety and performance standards.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 0.75 A
- Inductance: 0.061 H (61.000mH)
- Watt Loss: 10.1 W
- HP @ 480 VAC: 0.25 hp
- Impedance @ 480 VAC: 5 %
- HP @ 600 VAC: 0.33 hp
- Impedance @ 600 VAC: 5 %
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.6 lbs
- Gross Weight: 2.05 lbs
