RLW-0P7505 – MTE | Reactor, 49mH, 0.75amps, Open

$ 98.00

The MTE RLW-0P7505 reactor is part of the RLW series, engineered to protect and enhance the performance of electronic equipment by absorbing power line disturbances. This reactor has an inductance of 49mH and a current rating of 0.75A, making it suitable for various power conversion applications.

Available on backorder

SKU: RLW-0P7505 Category: Tag:
Inquire

Description

The MTE RLW-0P7505 reactor is part of the RLW series, engineered to protect and enhance the performance of electronic equipment by absorbing power line disturbances. This reactor has an inductance of 49mH and a current rating of 0.75A, making it suitable for various power conversion applications.

Features

  • RoHS and REACH Compliant: Ensures adherence to environmental and safety regulations.
  • Wide Voltage Range: Compatible with standard voltages from 208 to 690 VAC.
  • Amperage Ratings: Suitable for applications ranging from 0.5 to 750 Amps.
  • Single-Phase Drive Protection: Provides transient protection for single-phase drives.
  • Epoxy Impregnation: Reduces audible noise and enhances structural and moisture integrity.
  • Compact and Lightweight Design: Optimized for peak performance with a smaller size and lighter weight compared to standard reactors.
  • Multiple Mounting Options: Designed to accommodate various machine building needs.
  • Global Compatibility: Suitable for equipment intended for international markets.
  • Lower Horsepower Selection: Ideal for protecting smaller motors.

Specifications

  • Manufacturer: MTE
  • Model: RLW-0P7505
  • Series: RLW
  • Phase: 3
  • Enclosed Unit: No
  • Current Rating: 0.75 A
  • Inductance: 49mH (0.049 H)
  • Watt Loss: 8.8 W
  • Terminals: Terminal Block
  • Mounting: Surface
  • Approvals: CE, UL
  • Net Weight: 1.5 lbs
  • Gross Weight: 2.2 lbs
Weight 2.2 lbs
