Description
The MTE RLW-0P7503 reactor is engineered to provide reliable filtering and transient protection for industrial electrical systems. With an inductance of 31.000mH and a current rating of 0.75 amps, this reactor ensures stable voltage regulation and minimizes electrical noise in 3-phase configurations. It is designed to enhance equipment reliability by absorbing power line disturbances and optimizing performance in various industrial applications.
Features
- RoHS and REACH Compliant: Meets environmental and safety standards, suitable for industrial use.
- Wide Voltage Range: Supports standard voltages from 208 to 690 VAC, ensuring compatibility across different systems.
- Flexible Amperage Ratings: Available in a range from 0.5 to 750 Amps, adaptable to diverse power requirements.
- Transient Protection: Safeguards equipment from voltage spikes and fluctuations, extending equipment lifespan.
- Epoxy Impregnation: Reduces audible noise, enhances structural integrity, and provides moisture resistance.
- Compact and Lightweight: Designed for efficient installation, minimizing space requirements and weight in machine building applications.
- Global Design: Engineered for international standards compliance, facilitating deployment in globally shipped machines.
- Optimized Performance: Ensures peak operational efficiency with minimal power loss compared to traditional reactors.
- Lower Horsepower Selection: Ideal for protecting smaller motors and equipment from electrical disturbances.
- Certifications: CE and UL approved, ensuring adherence to global safety and performance standards.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 0.75 A
- Inductance: 0.031 H (31.000mH)
- Watt Loss: 6.6 W
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.5 lbs
- Gross Weight: 2.225 lbs
