RLW-07P606 – MTE | Reactor, 6mH, 7.6amps, Open

$ 172.00

The RLW-07P606 reactor belongs to MTE’s RLW series, known for its advanced filtering capabilities and compact design. It is an open-type reactor designed to ensure stable operation of industrial equipment by mitigating voltage spikes and electrical noise.

Available on backorder

SKU: RLW-07P606 Category: Tag:
Inquire

Description

The RLW-07P606 reactor belongs to MTE’s RLW series, known for its advanced filtering capabilities and compact design. It is an open-type reactor designed to ensure stable operation of industrial equipment by mitigating voltage spikes and electrical noise.

Features

  • RoHS and REACH Compliant: Meets environmental and safety standards.
  • Wide Voltage Compatibility: Supports standard voltages ranging from 208 to 690 VAC.
  • Amperage Ratings: Capable of handling currents from 0.5 to 750 Amps.
  • Transient Protection: Suitable for protecting single-phase drives from power line disturbances.
  • Crossover Tables: Available for compatibility with various standard reactors.
  • Epoxy Impregnation: Reduces audible noise, enhances structural integrity, and improves resistance to moisture.
  • Compact and Lightweight: Designed for space efficiency and ease of installation, reducing footprint and weight compared to traditional reactors.
  • Versatile Mounting Options: Provides flexibility in installation to meet specific machine building requirements.
  • Global Design: Facilitates deployment across international markets, meeting global standards.
  • Motor Protection: Particularly suitable for applications requiring lower horsepower protection.

Specifications

  • Manufacturer: MTE
  • Product Series: RLW
  • Family Series: MTE Line Reactors, RLW Series
  • Phase: 3
  • Enclosed Unit: No (Open)
  • Current Rating: 7.6 A
  • Inductance: 0.006 H (6.000 mH)
  • Watt Loss: 53.8 W
  • Impedance @ 600 VAC: 5%
  • HP @ 600 VAC: 5 hp
  • Terminals: Terminal Block
  • Mounting: Surface
  • Approvals: CE, UL
  • Net Weight: 4.2 lbs
  • Gross Weight: 5.15 lbs
