Description
The MTE RLW-07P601 reactor is designed to enhance the performance and reliability of industrial equipment by filtering power line disturbances and providing transient protection. With a current rating of 7.6 amps and an inductance of 1.500mH, this reactor is well-suited for applications involving single-phase drives, ensuring stable operation and extended equipment lifespan.
Features
- RoHS and REACH Compliant: Meets international environmental and safety standards.
- Wide Voltage Compatibility: Supports standard voltages from 208 to 690 VAC, ensuring versatility.
- Amperage Range: Available in ratings from 0.5 to 750 Amps, catering to various industrial needs.
- Transient Protection: Guards against voltage spikes and line disturbances, enhancing equipment longevity.
- Epoxy Impregnation: Reduces audible noise, improves structural integrity, and enhances resistance to moisture.
- Compact and Lightweight: Designed for space efficiency and easy integration into machine building applications.
- Global Design: Suitable for international shipping and application across different regions.
- Lower Horsepower Selection: Ideal for protecting smaller motors and equipment.
- Certifications: CE and UL approved, ensuring compliance with international standards for safety and performance.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 7.6 A
- Inductance: 0.0015 H (1.500mH)
- Watt Loss: 19.2 W
- HP @ 240 VAC: 2 hp
- Impedance @ 240 VAC: 3 %
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.8 lbs
- Gross Weight: 2.25 lbs
