Description
The RLW-04P806 reactor from MTE is designed to ensure the reliable operation of industrial equipment by filtering out power line disturbances and electrical noise. Its robust specifications and compact design make it suitable for various industrial applications where maintaining stable voltage and protecting machinery from electrical interference are critical.
Features
- RoHS and REACH Compliant: Adheres to environmental and safety standards.
- Wide Voltage Compatibility: Supports standard voltages from 208 to 690 VAC.
- Amperage Ratings: Ranges from 0.5 to 750 Amps.
- Transient Protection: Ideal for single-phase drives, safeguarding against voltage spikes and power disturbances.
- Crossover Tables: Available for compatibility with various standard reactors.
- Epoxy Impregnation: Reduces audible noise, improves structural integrity, and enhances resistance to moisture.
- Compact and Lightweight: Designed for space efficiency, featuring reduced size and weight compared to traditional reactors.
- Versatile Mounting Options: Offers flexibility in installation to meet specific machine building requirements.
- Global Design: Suitable for international applications, meeting global standards for reliability and performance.
- Motor Protection: Designed for applications requiring lower horsepower protection.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No (Open)
- Current Rating: 4.8 A
- Inductance: 0.01 H (10.000 mH)
- Watt Loss: 40.1 W
- Impedance @ 600 VAC: 5%
- HP @ 600 VAC: 3 hp
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 4 lbs
- Gross Weight: 4 lbs
