Description
The RLW-04P805 reactor is designed to ensure stable operation of industrial machinery by filtering power line disturbances and reducing electrical noise. Its robust specifications and compact form factor make it suitable for various industrial environments where maintaining stable voltage and protecting equipment from electrical interference are critical.
Features
- RoHS and REACH Compliant: Meets environmental and safety standards.
- Wide Voltage Range: Supports standard voltages from 208 to 690 VAC.
- Amperage Ratings: Available in ratings from 0.5 to 750 Amps.
- Transient Protection: Suitable for single-phase drives, protecting against voltage spikes and disturbances.
- Crossover Tables: Facilitates compatibility with other standard reactors.
- Epoxy Impregnation: Reduces audible noise, enhances structural durability, and improves moisture resistance.
- Compact and Lightweight Design: Smaller and lighter compared to conventional reactors, facilitating easier installation.
- Versatile Mounting Options: Offers flexibility for different machine building needs.
- Global Design: Designed to meet international standards, suitable for global shipping and applications.
- Low Horsepower Selection: Ideal for applications requiring motor protection at lower horsepower ratings.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No (Open)
- Current Rating: 4.8 A
- Inductance: 0.0077 H (7.700 mH)
- Watt Loss: 37.5 W
- Impedance @ 240 VAC: 5%
- Impedance @ 480 VAC: 5%
- Impedance @ 600 VAC: 3%
- HP @ 240 VAC: 0.5 hp
- HP @ 480 VAC: 3 hp
- HP @ 600 VAC: 3 hp
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 2.8 lbs
- Gross Weight: 2.8 lbs
