Description
The MTE RLW-04P801 reactor is an open, 3-phase line reactor designed to provide effective filtering for power line disturbances, thereby improving the performance and durability of industrial equipment. With a current rating of 4.8 amps and an inductance of 2.3mH, this reactor is tailored for specific applications requiring lower amperage and higher inductance, ensuring optimal performance in a compact and lightweight design.
Features
- RoHS and REACH Compliant: Ensures the reactor meets international environmental and safety standards.
- Voltage Compatibility: Operates effectively across standard voltages from 208 to 690 VAC.
- Wide Amperage Range: Suitable for applications ranging from 0.5 to 750 Amps.
- Transient Protection: Ideal for single-phase drive applications, providing protection against transient power disturbances.
- Epoxy Impregnation: Reduces noise levels and improves structural integrity and moisture resistance.
- Compact and Lightweight: Designed for optimal performance with a smaller footprint compared to traditional reactors.
- Flexible Mounting Options: Multiple mounting configurations available to meet various installation needs.
- Global Compatibility: Engineered for worldwide application, facilitating international shipping and compliance.
- Certifications: CE and UL approved, ensuring adherence to rigorous safety and performance standards.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 4.8 A
- Inductance: 0.0023 H (2.3mH)
- Watt Loss: 13.8 W
- HP @ 240 VAC: 1 hp
- Impedance @ 240 VAC: 3 %
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.7 lbs
- Gross Weight: 2.75 lbs
