Description
The RLW-03P406 reactor by MTE is designed to ensure stable operation of industrial equipment by filtering power line disturbances and minimizing electrical noise. Its robust specifications and compact design make it suitable for various industrial applications where maintaining stable voltage and protecting machinery from electrical interference are critical.
Feature
- RoHS and REACH Compliant: Complies with environmental and safety standards.
- Wide Voltage Compatibility: Supports standard voltages from 208 to 690 VAC.
- Amperage Ratings: Available in ratings from 0.5 to 750 Amps.
- Transient Protection: Suitable for single-phase drives, protecting against voltage spikes and power disturbances.
- Crossover Tables: Facilitates compatibility with various standard reactors.
- Epoxy Impregnation: Minimizes audible noise, enhances structural integrity, and improves moisture resistance.
- Compact and Lightweight: Designed with reduced size and weight compared to traditional reactors.
- Multiple Mounting Options: Offers flexibility in installation to meet specific machine building requirements.
- Global Design: Designed for international applications, meeting global standards for reliability and performance.
- Motor Protection: Tailored for applications requiring lower horsepower protection.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No (Open)
- Current Rating: 3.4 A
- Inductance: 0.014 H (14.000 mH)
- Watt Loss: 31.5 W
- Impedance @ 600 VAC: 5%
- HP @ 600 VAC: 1.5 hp, 2 hp
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 2.8 lbs
- Gross Weight: 3.85 lbs
