Description
The MTE RLW-03P401 reactor is designed to provide effective filtering and transient protection for industrial electrical systems. With an inductance of 3.200mH and a current rating of 3.4 amps, this reactor is particularly suitable for 3-phase configurations, ensuring stable voltage regulation and minimizing electrical noise. It is designed to enhance equipment reliability by absorbing power line disturbances and optimizing performance in a wide range of applications.
Features
- RoHS and REACH Compliant: Complies with environmental and safety standards, suitable for various industrial environments.
- Wide Voltage Range: Supports standard voltages from 208 to 690 VAC, ensuring compatibility across different systems.
- Flexible Amperage Ratings: Available in a range from 0.5 to 750 Amps, accommodating diverse power requirements.
- Transient Protection: Protects equipment from voltage spikes and fluctuations, extending equipment lifespan and reliability.
- Epoxy Impregnation: Minimizes audible noise, enhances structural integrity, and provides resistance to moisture.
- Compact and Lightweight: Designed for space-efficient installation, reducing footprint and weight in machine building applications.
- Global Design: Engineered to meet international standards, facilitating deployment in machines shipped globally.
- Optimized Performance: Ensures peak operational efficiency with minimal power loss compared to conventional reactors.
- Lower Horsepower Selection: Ideal for protecting smaller motors and equipment from electrical disturbances.
- Certifications: CE and UL approved, ensuring compliance with global safety and performance standards.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 3.4 A
- Inductance: 0.0032 H (3.200mH)
- Watt Loss: 12.3 W
- HP @ 240 VAC: 0.75 hp
- Impedance @ 240 VAC: 3 %
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.6 lbs
- Gross Weight: 2.05 lbs
