Description
The MTE RLW-02P101 reactor is designed to enhance the performance and reliability of industrial electrical systems by mitigating power line disturbances. With an inductance of 5.300mH and a current rating of 2.1 amps, it effectively filters out harmonics and improves the overall power quality in 3-phase configurations. This reactor is ideal for applications requiring stable voltage regulation and protection against transient voltage spikes.
Features
- RoHS and REACH Compliant: Meets environmental and safety standards, suitable for various industrial applications.
- Wide Voltage Range: Supports standard voltages from 208 to 690 VAC, ensuring compatibility across different systems.
- Flexible Amperage Ratings: Available in a range from 0.5 to 750 Amps, catering to diverse power requirements.
- Transient Protection: Protects equipment from voltage spikes and fluctuations, extending operational life.
- Epoxy Impregnation: Reduces audible noise, enhances structural integrity, and provides resistance to moisture.
- Compact and Lightweight: Designed for space-efficient installation and integration into machine building applications.
- Global Design: Engineered to meet international standards, facilitating deployment in machines shipped worldwide.
- Optimized Performance: Ensures peak operational efficiency with minimal power loss, surpassing conventional reactors.
- Suitability for Lower Horsepower: Ideal for protecting smaller motors and equipment from electrical disturbances.
- Certifications: CE and UL approved, ensuring adherence to global safety and performance standards.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 2.1 A
- Inductance: 0.0053 H (5.300mH)
- Watt Loss: 9 W
- HP @ 240 VAC: 0.5 hp
- Impedance @ 240 VAC: 3 %
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.5 lbs
- Gross Weight: 1.985 lbs
