Description
The MTE RLW-020007 reactor is engineered to ensure the smooth operation and longevity of electronic equipment by effectively absorbing power line disturbances. As part of the RLW series, this reactor offers cutting-edge filtering capabilities for various industrial applications. With a high current rating of 200A and an inductance of 0.34mH, it provides robust protection while maintaining a compact and lightweight design.
Features
- RoHS and REACH Compliant: Meets international environmental and safety standards.
- Wide Voltage Compatibility: Compatible with standard voltages from 208 to 690 VAC.
- High Amperage Rating: Capable of handling up to 200 Amps of current.
- Transient Protection: Ideal for safeguarding single-phase drives against power surges.
- Epoxy Impregnation: Reduces audible noise and enhances structural integrity.
- Compact and Lightweight Design: Ensures peak performance without adding bulk.
- Multiple Mounting Options: Accommodates various machine building needs.
- Global Perspective: Designed for worldwide compatibility and shipment.
- Lower Horsepower Selection: Suitable for protecting smaller motors from disturbances.
Specifications
- Manufacturer: MTE
- Model: RLW-020007
- Series: RLW
- Phase: 3
- Enclosed Unit: No
- Current Rating: 200 A
- Inductance: 0.34mH (0.00034 H)
- Watt Loss: 509 W
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Comments: At 690 VAC – 250/275 HP, 4% Impedance
- Net Weight: 91 lbs
- Gross Weight: 91 lbs
