Description
The MTE Reactor RLW-020005 is an essential component in the RLW Series, meticulously designed to provide outstanding performance and protection for power conversion systems. With an inductance of 0.2mH and a robust current rating of 200 amps, this reactor efficiently absorbs power line disturbances, ensuring prolonged equipment longevity and reliability. Its open design makes it suitable for various applications where enclosure space is not a concern. The reactor is RoHS and REACH compliant, meeting stringent environmental and safety standards. Additionally, epoxy impregnation minimizes audible noise while enhancing structural and moisture integrity, ensuring optimal operation across diverse environments.
Features
- RoHS and REACH Compliant: Meets stringent environmental and safety standards.
- Wide Voltage Compatibility: Compatible with standard voltages ranging from 208 to 690 VAC.
- Flexible Amperage Ratings: Offers ratings from 0.5 to 750 Amps.
- Single-Phase Drive Protection: Provides effective transient protection for single-phase drives.
- Crossover Tables: Facilitates straightforward comparison with other standard reactors.
- Epoxy Impregnation: Minimizes audible noise and enhances structural and moisture integrity.
- Compact and Lightweight Design: Optimized for peak performance with reduced size and weight.
- Global Design: Facilitates international machine shipments with multiple mounting options.
- Lower Horsepower Selection: Ideal for safeguarding smaller motors.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Current Rating: 200 A
- Inductance: 0.0002 H
- Watt Loss: 293 W
- HP @ 480 VAC: 175 hp, 150 hp
- Impedance @ 480 VAC: 5 %
- HP @ 600 VAC: 225 hp, 200 hp
- Impedance @ 600 VAC: 5 %
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 75 lbs
- Manufacturer Part Number: RLW-020005
- Item Number: RLW-020005
