Description
The MTE RLW-020001 reactor is designed to enhance the stability and efficiency of industrial power systems. With a current rating of 200 amps and an inductance of 0.06mH, it effectively filters power line disturbances, ensuring the smooth operation of equipment. This reactor is RoHS and REACH compliant, meeting stringent environmental standards. Its open design allows for efficient heat dissipation, ensuring reliable performance even in demanding environments. The epoxy impregnation minimizes audible noise and enhances structural integrity, making it suitable for various industrial applications. Terminal block connections simplify wiring, facilitating ease of installation. With CE and UL approvals, this reactor guarantees compliance with international quality and safety standards.
Features
- RoHS and REACH Compliant: Meets environmental standards.
- Wide Voltage Compatibility: Supports standard voltages from 208 to 690 VAC.
- Flexible Amperage Ratings: Ranges from 0.5 to 750 Amps.
- Transient Protection: Shields equipment from power line disturbances.
- Efficient Heat Dissipation: Open design for optimal cooling.
- Epoxy Impregnation: Minimizes noise and enhances structural integrity.
- Terminal Block Connections: Simplify wiring for easy installation.
- Approvals: CE, UL
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 200 A
- Inductance: 0.06 H
- Watt Loss: 158.5 W
- HP @ 240 VAC: 75 hp
- Impedance @ 240 VAC: 3 %
- Terminals: Terminal Block
- Mounting: Surface
- Manufacturer Part Number: RLW-020001
- Item Number: RLW-020001
- Ships Factory Direct: No
- Approvals: CE, UL
- Net Weight: 40.4 lbs
- Gross Weight: 40.4 lbs
