Description
The RLW-01P606 reactor from MTE is designed to ensure stable operation of industrial machinery by filtering power line disturbances and reducing electrical noise. Its robust specifications and compact design make it suitable for various industrial environments where maintaining stable voltage and protecting equipment from electrical interference are crucial.
Features:
- RoHS and REACH Compliant: Complies with environmental and safety standards.
- Wide Voltage Range: Supports standard voltages from 208 to 690 VAC.
- Amperage Ratings: Available in a range from 0.5 to 750 Amps.
- Transient Protection: Ideal for single-phase drives, protecting against voltage spikes and disturbances.
- Crossover Tables: Facilitates compatibility with other standard reactors.
- Epoxy Impregnation: Minimizes audible noise, enhances structural durability, and improves moisture resistance.
- Compact and Lightweight: Designed for peak performance in a compact and lightweight form, suitable for diverse industrial applications.
- Multiple Mounting Options: Provides flexibility to accommodate various machine building needs.
- Global Design: Designed to meet global standards, facilitating international shipping and applications.
- Low Horsepower Selection: Suitable for applications requiring motor protection at lower horsepower ratings.
Specification
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No (Open)
- Current Rating: 1.6 A
- Inductance: 0.029 H (29.000 mH)
- Watt Loss: 17.7 W
- Impedance @ 480 VAC: 3%
- Impedance @ 600 VAC: 5%
- HP @ 480 VAC: 0.33 hp
- HP @ 600 VAC: 0.75 hp
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.7 lbs
- Gross Weight: 2.7 lbs
