Description
The MTE RLW-01P603 reactor is a compact and efficient 3-phase line reactor designed to provide superior filtering and protection against power line disturbances in industrial applications. With a current rating of 1.6 amps and an inductance of 14.000mH, this reactor is specifically engineered to enhance the reliability and performance of equipment operating with single-phase drives, ensuring smooth operation and extended lifespan.
Features
- RoHS and REACH Compliant: Complies with international environmental and safety standards.
- Voltage Compatibility: Supports standard voltages from 208 to 690 VAC, ensuring versatile application.
- Wide Amperage Range: Suitable for applications ranging from 0.5 to 750 Amps.
- Transient Protection: Protects single-phase drives from voltage spikes and line disturbances.
- Epoxy Impregnation: Reduces audible noise, enhances structural integrity, and improves resistance to moisture.
- Compact and Lightweight: Designed for minimal footprint and easy installation, suitable for various machine building needs.
- Global Design: Facilitates worldwide shipping and application compatibility.
- Lower Horsepower Selection: Ideal for applications requiring smaller motor protection needs.
- Certifications: CE and UL approved, ensuring compliance with international safety and performance standards.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 1.6 A
- Inductance: 0.014 H (14.000mH)
- Watt Loss: 10.9 W
- HP @ 240 VAC: 0.25 hp
- Impedance @ 240 VAC: 5 %
- HP @ 480 VAC: 0.75 hp
- Impedance @ 480 VAC: 3 %
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.6 lbs
- Gross Weight: 2.25 lbs
