Description
The MTE RLW-01P601 reactor is designed to provide robust transient protection and enhance the operational efficiency of industrial equipment. With an inductance of 6.900mH and a current rating of 1.6 amps, it effectively filters power line disturbances and ensures stable performance for 3-phase systems. This reactor is particularly suited for applications requiring reliable voltage stabilization and noise reduction.
Features
- RoHS and REACH Compliant: Meets environmental and safety standards for industrial applications.
- Wide Voltage Range: Supports standard voltages from 208 to 690 VAC, ensuring compatibility across various systems.
- Flexible Amperage Ratings: Available in a range from 0.5 to 750 Amps, catering to diverse power requirements.
- Transient Protection: Safeguards against voltage spikes and fluctuations, enhancing equipment longevity and reliability.
- Epoxy Impregnation: Reduces audible noise and enhances structural integrity, providing resilience against moisture and vibrations.
- Compact and Lightweight: Designed for space-efficient installation, suitable for integration into machine building applications.
- Global Design: Engineered to meet international standards, facilitating deployment in machines shipped worldwide.
- Optimized Performance: Delivers peak operational efficiency in a compact and lightweight form factor, surpassing conventional reactors.
- Suitability for Lower Horsepower: Ideal for protecting smaller motors and equipment from electrical disturbances.
- Certifications: CE and UL approved, ensuring adherence to global safety and performance standards.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 1.6 A
- Inductance: 0.0069 H (6.900mH)
- Watt Loss: 6.9 W
- HP @ 240 VAC: 0.25 hp
- Impedance @ 240 VAC: 3 %
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.5 lbs
- Gross Weight: 2.47 lbs
