Description
The MTE RLW-01P106 reactor is designed to enhance the performance and reliability of industrial equipment by filtering power line disturbances and providing transient protection. With a current rating of 1.1 amps and an inductance of 42.000mH, this reactor is well-suited for applications requiring stable operation and protection against voltage fluctuations.
Features
- RoHS and REACH Compliant: Meets international environmental and safety standards.
- Wide Voltage Compatibility: Supports standard voltages from 208 to 690 VAC, ensuring versatility.
- Amperage Range: Available in ratings from 0.5 to 750 Amps, catering to various industrial needs.
- Transient Protection: Guards against voltage spikes and line disturbances, enhancing equipment longevity.
- Epoxy Impregnation: Reduces audible noise, improves structural integrity, and enhances resistance to moisture.
- Compact and Lightweight: Designed for space efficiency and easy integration into machine building applications.
- Global Design: Suitable for international shipping and application across different regions.
- Lower Horsepower Selection: Ideal for protecting smaller motors and equipment.
- Certifications: CE and UL approved, ensuring compliance with international standards for safety and performance.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 1.1 A
- Inductance: 0.042 H (42.000mH)
- Watt Loss: 11.9 W
- HP @ 480 VAC: 0.33 hp
- Impedance @ 480 VAC: 5 %
- HP @ 600 VAC: 0.5 hp
- Impedance @ 600 VAC: 5 %
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.7 lbs
- Gross Weight: 2.34 lbs
