Description
The MTE RLW-01P105 reactor is designed to ensure the smooth operation and longevity of industrial equipment by effectively filtering power line disturbances and providing transient protection. With a current rating of 1.1 amps and an inductance of 33.000mH, this reactor is suitable for applications requiring stable voltage conditions and protection against electrical fluctuations.
Features
- RoHS and REACH Compliant: Meets stringent environmental and safety standards.
- Wide Voltage Range: Compatible with standard voltages from 208 to 690 VAC, ensuring versatility in industrial applications.
- Amperage Flexibility: Available in ratings ranging from 0.5 to 750 Amps, catering to various power requirements.
- Transient Protection: Guards against voltage spikes and power line disturbances, enhancing equipment reliability.
- Epoxy Impregnation: Minimizes audible noise, enhances structural integrity, and improves resistance to moisture.
- Compact and Lightweight: Designed for space efficiency and ease of installation in machine building applications.
- Global Application: Designed with international shipping in mind, suitable for deployment across different regions.
- Optimized Design: Engineered for peak performance in a compact, lightweight package, offering advantages over standard reactors.
- Lower Horsepower Compatibility: Ideal for safeguarding smaller motors and equipment from electrical issues.
- Certifications: CE and UL approved, ensuring compliance with international standards for safety and performance.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 1.1 A
- Inductance: 0.033 H (33.000mH)
- Watt Loss: 10.1 W
- HP @ 480 VAC: 0.25 hp
- Impedance @ 480 VAC: 3 %
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.6 lbs
- Gross Weight: 2.7 lbs
