Description
The MTE RLW-01P101 reactor is part of the RLW series, designed to protect and improve the performance of electronic equipment by absorbing power line disturbances. This reactor features an inductance of 10mH and a current rating of 1.1A, making it suitable for a wide range of power conversion applications.
Features
- RoHS and REACH Compliant: Meets environmental and safety standards.
- Wide Voltage Range: Compatible with standard voltages from 208 to 690 VAC.
- Amperage Ratings: Suitable for applications with current ratings from 0.5 to 750 Amps.
- Single-Phase Drive Protection: Provides transient protection for single-phase drives.
- Epoxy Impregnation: Reduces audible noise and enhances structural and moisture integrity.
- Compact and Lightweight Design: Optimized for peak performance with a smaller size and lighter weight compared to standard reactors.
- Multiple Mounting Options: Designed to accommodate various machine building needs.
- Global Compatibility: Suitable for equipment intended for international markets.
- Lower Horsepower Selection: Ideal for protecting smaller motors.
Specifications
- Manufacturer: MTE
- Model: RLW-01P101
- Series: RLW
- Phase: 3
- Enclosed Unit: No
- Current Rating: 1.1 A
- Inductance: 10mH (0.01 H)
- Watt Loss: 4.8 W
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.5 lbs
- Gross Weight: 2.15 lbs
