Description
The MTE RLW-016007 reactor is designed to ensure the smooth operation and longevity of electronic equipment by absorbing power line disturbances. Part of the RLW series, this reactor offers state-of-the-art filtering capabilities for various industrial applications. With a current rating of 160A and an inductance of 0.47mH, it provides robust protection while maintaining a compact and lightweight design.
Features
- RoHS and REACH Compliant: Meets international environmental and safety standards.
- Wide Voltage Compatibility: Compatible with standard voltages from 208 to 690 VAC.
- High Amperage Rating: Capable of handling up to 160 Amps of current.
- Transient Protection: Ideal for safeguarding single-phase drives against power surges.
- Epoxy Impregnation: Reduces audible noise and enhances structural integrity.
- Compact and Lightweight Design: Ensures peak performance without adding bulk.
- Multiple Mounting Options: Accommodates various machine building needs.
- Global Perspective: Designed for worldwide compatibility and shipment.
- Lower Horsepower Selection: Suitable for protecting smaller motors from disturbances.
Specifications
- Manufacturer: MTE
- Model: RLW-016007
- Series: RLW
- Phase: 3
- Enclosed Unit: No
- Current Rating: 160 A
- Inductance: 0.47mH (0.00047 H)
- Watt Loss: 561 W
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Comments: At 690 VAC – 200/225 HP, 4% Impedance
- Net Weight: 75 lbs
