Description
The MTE RLW-016001 reactor is engineered to provide effective transient protection and optimize the performance of industrial power systems. With a current rating of 160 amps and an inductance of 0.08mH, this reactor is ideal for various applications, offering robust filtering for 4 or 6 pulse rectifiers or power conversion units. It meets RoHS and REACH compliance standards, demonstrating its commitment to environmental responsibility. The reactor’s epoxy impregnation ensures minimized audible noise and enhanced structural integrity, guaranteeing reliable operation even in demanding environments. Its open design facilitates efficient heat dissipation, contributing to its longevity and performance. The reactor is suitable for standard voltages ranging from 208 to 690 VAC and offers compatibility with single-phase drives. It features a compact and lightweight design, making it suitable for diverse machine building needs and global shipping. With CE and UL approvals, it meets rigorous international quality and safety standards.
Features
- RoHS and REACH Compliant: Environmentally responsible design.
- Wide Voltage Compatibility: Supports standard voltages from 208 to 690 VAC.
- Transient Protection: Guards against power line disturbances.
- Epoxy Impregnation: Minimizes audible noise and enhances durability.
- Open Design: Facilitates efficient heat dissipation.
- Compact and Lightweight: Suitable for various machine building needs.
- Global Shipping: Designed from a global perspective for worldwide compatibility.
- Approvals: CE, UL
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 160 A
- Inductance: 0.08 H
- Watt Loss: 109.5 W
- HP @ 240 VAC: 50 hp, 60 hp
- Impedance @ 240 VAC: 3 %
- Terminals: Terminal Block
- Mounting: Surface
- Manufacturer Part Number: RLW-016001
- Item Number: RLW-016001
- Ships Factory Direct: No
- Approvals: CE, UL
- Net Weight: 34 lbs
