Description
The MTE RLW-013007 reactor is engineered to ensure the smooth operation and longevity of electronic equipment by absorbing power line disturbances. It belongs to the RLW series, featuring a compact and lightweight design without compromising performance. With an inductance of 0.56mH and a robust current rating of 130A, this reactor offers reliable protection for various industrial applications.
Features
- RoHS and REACH Compliant: Complies with international environmental and safety standards.
- Wide Voltage Compatibility: Suitable for all standard voltages from 208 to 690 VAC.
- High Amperage Rating: Capable of handling up to 130 Amps of current.
- Transient Protection: Ideal for safeguarding single-phase drives against power surges.
- Epoxy Impregnation: Reduces audible noise while enhancing structural and moisture integrity.
- Compact and Lightweight: Designed for peak performance in a space-efficient package.
- Multiple Mounting Options: Offers flexibility in installation to meet diverse machine building requirements.
- Global Design: Engineered from a global perspective, allowing for international shipment and compatibility.
- Lower Horsepower Selection: Suitable for protecting smaller motors from power line disturbances.
Specifications
- Manufacturer: MTE
- Model: RLW-013007
- Series: RLW
- Phase: 3
- Enclosed Unit: No
- Current Rating: 130 A
- Inductance: 0.56mH (0.00056 H)
- Watt Loss: 480 W
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Comments: At 690 VAC – 175 HP, 4% Impedance
- Net Weight: 80 lbs
