Description
The MTE RLW-013001 reactor is part of the RLW series designed for superior power line disturbance absorption, ensuring extended equipment life and enhanced performance. This reactor, with a current rating of 130 amps and an inductance of 0.095mH, is engineered to provide robust transient protection and efficient filtering for industrial power systems. Its open design allows for efficient heat dissipation, making it ideal for environments where enclosure is not required.
Features
- RoHS and REACH Compliant: Environmentally friendly and safe for use.
- Voltage Compatibility: Suitable for a wide range of standard voltages from 208 to 690 VAC.
- Transient Protection: Ideal for single-phase drives and various power conversion units.
- Epoxy Impregnation: Minimizes audible noise and enhances structural integrity and moisture resistance.
- Compact and Lightweight: Optimally designed for peak performance with a smaller size and weight compared to standard reactors.
- Multiple Mounting Options: Provides flexibility to meet diverse machine building needs.
- Global Compatibility: Designed for worldwide use, enabling machines to be shipped globally.
- Approvals: CE, UL certified ensuring adherence to international safety standards.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 130 A
- Inductance: 0.095 mH
- Watt Loss: 131.5 W
- HP @ 240 VAC: 40 hp
- Impedance @ 240 VAC: 3 %
- Terminals: Terminal Block
- Mounting: Surface
- Manufacturer Part Number: RLW-013001
- Item Number: RLW-013001
- Ships Factory Direct: No
- Net Weight: 26 lbs
- Approvals: CE, UL
