Description
The MTE RLW-010407 reactor is designed to safeguard electronic equipment from power line disturbances, ensuring uninterrupted operation and longevity. Part of the RLW series, this reactor features an inductance of 0.67mH and a high current rating of 104A, making it suitable for demanding industrial applications.
Features
- RoHS and REACH Compliant: Meets international environmental and safety standards.
- Wide Voltage Range: Compatible with standard voltages from 208 to 690 VAC.
- High Amperage Rating: Suitable for applications requiring up to 104 Amps of current.
- Transient Protection: Ideal for safeguarding single-phase drives from power surges.
- Epoxy Impregnation: Reduces audible noise and enhances structural integrity.
- Compact and Lightweight: Designed for peak performance in a compact form factor.
- Multiple Mounting Options: Offers flexibility in installation to meet various machine building needs.
- Global Compatibility: Designed for use in machinery intended for global markets.
- Lower Horsepower Selection: Provides protection for smaller motors.
Specifications
- Manufacturer: MTE
- Model: RLW-010407
- Series: RLW
- Phase: 3
- Enclosed Unit: No
- Current Rating: 104 A
- Inductance: 0.67mH (0.00067 H)
- Watt Loss: 256 W
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Comments: At 690 VAC – 150 HP, 4% Impedance
- Net Weight: 57 lbs
