RLW-010401 – MTE | Reactor, 0.12mH, 104amps, Open

$ 507.60

The MTE RLW-010401 reactor is part of the RLW series, designed to offer high-performance power line filtering for industrial applications. With a current rating of 104 amps and an inductance of 0.12mH, this open reactor is optimal for various three-phase systems. Its open design provides flexibility for integration into different setups, ensuring efficient transient protection and power disturbance absorption.

Available on backorder

SKU: RLW-010401 Category: Tag:
Inquire

Description

The MTE RLW-010401 reactor is part of the RLW series, designed to offer high-performance power line filtering for industrial applications. With a current rating of 104 amps and an inductance of 0.12mH, this open reactor is optimal for various three-phase systems. Its open design provides flexibility for integration into different setups, ensuring efficient transient protection and power disturbance absorption.

Features

  • RoHS and REACH Compliant: Ensures the reactor meets strict environmental and safety regulations.
  • Wide Voltage Range: Compatible with standard voltages from 208 to 690 VAC.
  • Versatile Amperage Handling: Suitable for applications with amperage ratings from 0.5 to 750 Amps.
  • Transient Protection: Designed for use with single-phase drives to mitigate transient disturbances.
  • Epoxy Impregnation: Reduces audible noise and enhances moisture resistance and structural integrity.
  • Compact and Lightweight: Offers peak performance with a smaller footprint and reduced weight compared to traditional reactors.
  • Multiple Mounting Options: Flexible mounting options to suit various machine configurations.
  • Global Design Compatibility: Suitable for international shipping and use, ensuring compliance with global standards.
  • Certifications: CE and UL approved for international safety and performance standards.

Specifications

  • Manufacturer: MTE
  • Product Series: RLW
  • Family Series: MTE Line Reactors, RLW Series
  • Phase: 3
  • Enclosed Unit: No
  • Current Rating: 104 A
  • Inductance: 0.00012 H (0.12mH)
  • Watt Loss: 94 W
  • HP @ 240 VAC: 30 hp
  • Impedance @ 240 VAC: 3 %
  • Terminals: Terminal Block
  • Mounting: Surface
  • Manufacturer Part Number: RLW-010401
  • Item Number: RLW-010401
  • Ships Factory Direct: No
  • Net Weight: 22 lbs
  • Gross Weight: 22.02 lbs
  • Approvals: CE, UL
Weight 22 lbs
