Description
The MTE RLW-00P506 reactor is part of the RLW series, specifically designed to enhance the performance and longevity of electronic equipment by absorbing power line disturbances. This reactor features a high inductance of 92mH and is rated for 0.5A, making it suitable for a wide range of power conversion applications.
Features
- RoHS and REACH Compliant: Meets environmental and safety standards.
- Voltage Range: Compatible with standard voltages from 208 to 690 VAC.
- Amperage Ratings: Suitable for applications from 0.5 to 750 Amps.
- Single-Phase Drive Protection: Ideal for transient protection in single-phase drives.
- Epoxy Impregnation: Reduces audible noise and improves structural and moisture integrity.
- Compact Design: Optimally designed for peak performance with a smaller size and lighter weight than standard reactors.
- Multiple Mounting Options: Accommodates various machine building needs.
- Global Compatibility: Designed for machines intended for international markets.
- Lower Horsepower Selection: Suitable for protecting smaller motors.
Specifications
- Manufacturer: MTE
- Model: RLW-00P506
- Series: RLW
- Phase: 3
- Enclosed Unit: No
- Current Rating: 0.5 A
- Inductance: 92mH (0.092 H)
- Watt Loss: 5.4 W
- Horsepower @ 600 VAC: 0.25 hp
- Impedance @ 600 VAC: 5 %
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.6 lbs
- Gross Weight: 2.6 lbs
