Description
The MTE RLW-00P505 reactor is a part of the RLW series, designed to protect and extend the life of your equipment by mitigating power line disturbances. With an inductance of 74mH and a current rating of 0.5A, this reactor offers advanced filtering for a variety of power conversion applications.
Features
- Compliance: RoHS and REACH compliant, ensuring environmental and safety standards are met.
- Versatility: Suitable for standard voltages ranging from 208 to 690 VAC.
- Wide Amperage Range: Suitable for applications from 0.5 to 750 Amps.
- Single-Phase Application: Ideal for single-phase drives, providing transient protection.
- Noise Reduction: Epoxy impregnation minimizes audible noise and enhances structural and moisture integrity.
- Compact Design: Optimally designed for peak performance with a compact and lightweight structure.
- Global Compatibility: Designed for global use, accommodating various machine building needs.
Specifications
- Manufacturer: MTE
- Model: RLW-00P505
- Series: RLW
- Phase: 3
- Enclosed Unit: No
- Current Rating: 0.5 A
- Inductance: 74mH (0.074 H)
- Watt Loss: 4.8 W
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.6 lbs
- Gross Weight: 2.3 lbs
