Description
The MTE RLW-00P503 reactor is part of the RLW series designed to extend the life of your equipment by mitigating power line disturbances. With an inductance of 46mH and a current rating of 0.5A, this reactor is a state-of-the-art filtering solution suitable for various applications, including single-phase drives for transient protection.
Features
- Compliance: RoHS and REACH compliant, ensuring it meets environmental and safety standards.
- Versatility: Available in standard voltages from 208 to 690 VAC, catering to a wide range of applications.
- Amperage Range: Covers a broad range from 0.5 to 750 Amps.
- Single-Phase Application: Ideal for use in single-phase drives for transient protection.
- Noise Reduction: Epoxy impregnation minimizes audible noise while enhancing structural and moisture integrity.
- Compact Design: Smaller size and weight compared to other standard reactors, designed for optimal performance.
- Global Compatibility: Designed for global application, allowing machines to be shipped worldwide.
Specifications
- Manufacturer: MTE
- Model: RLW-00P503
- Series: RLW
- Phase: 3
- Enclosed Unit: No
- Current Rating: 0.5 A
- Inductance: 46mH (0.046 H)
- Watt Loss: 3.6 W
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 1.5 lbs
