Description
The MTE RLW-008307 reactor is designed to enhance the longevity and performance of electronic equipment by mitigating power line disturbances. This model, part of the RLW series, features an inductance of 0.91mH and a current rating of 83A, suitable for various industrial applications.
Features
- RoHS and REACH Compliant: Ensures compliance with international environmental and safety standards.
- Wide Voltage Range: Compatible with standard voltages from 208 to 690 VAC.
- Amperage Ratings: Suitable for applications with current ratings from 0.5 to 750 Amps.
- Single-Phase Drive Protection: Provides transient protection for single-phase drives.
- Epoxy Impregnation: Reduces audible noise and enhances structural and moisture integrity.
- Compact and Lightweight Design: Optimized for peak performance with a smaller size and lighter weight compared to standard reactors.
- Multiple Mounting Options: Accommodates various machine building needs.
- Global Compatibility: Designed for equipment intended for international markets.
- Lower Horsepower Selection: Ideal for protecting smaller motors.
Specifications
- Manufacturer: MTE
- Model: RLW-008307
- Series: RLW
- Phase: 3
- Enclosed Unit: No
- Current Rating: 83 A
- Inductance: 0.91mH (0.00091 H)
- Watt Loss: 240 W
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Comments: At 690 VAC – 100 HP, 4% Impedance
- Net Weight: 54 lbs
