Description
The MTE RLW-008305 reactor is engineered to ensure the efficient and stable operation of industrial power systems. With a current rating of 83 amps and an inductance of 0.51mH, it effectively filters power line disturbances, offering transient protection and enhancing system performance. Compliant with RoHS and REACH standards, this reactor demonstrates environmental responsibility. Its open design facilitates easy installation and maintenance, making it suitable for various applications, including single-phase drives. Epoxy impregnation minimizes audible noise and improves structural integrity and moisture resistance. Featuring multiple mounting options, this reactor offers flexibility in machine building needs. With CE and UL approvals, it meets international quality and safety standards.
Features
- RoHS and REACH Compliant: Environmentally responsible design.
- Wide Voltage Compatibility: Supports standard voltages from 208 to 690 VAC.
- Flexible Amperage Ratings: Ranges from 0.5 to 750 Amps.
- Transient Protection: Shields equipment from power line disturbances.
- Epoxy Impregnation: Minimizes audible noise and enhances structural integrity.
- Open Design: Facilitates easy installation and maintenance.
- Multiple Mounting Options: Offers flexibility in machine building needs.
- Approvals: CE, UL
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 83 A
- Inductance: 0.51 H
- Watt Loss: 19.6 W
- HP @ 480 VAC: 50 hp, 60 hp
- Impedance @ 480 VAC: 5 %
- HP @ 600 VAC: 75 hp
- Impedance @ 600 VAC: 5 %
- Terminals: Terminal Block
- Mounting: Surface
- Manufacturer Part Number: RLW-008305
- Item Number: RLW-008305
- Ships Factory Direct: No
- Approvals: CE, UL
- Net Weight: 35 lbs
- Gross Weight: 40.585 lbs
