Description
The MTE RLW-008301 reactor is a high-capacity line reactor designed to protect electrical equipment from power line disturbances. With an inductance of 0.17mH and a current rating of 83 amps, it is ideal for demanding industrial applications, providing effective filtering and transient protection. This reactor is part of the RLW series, known for its compact, lightweight design and robust performance.
Features
- RoHS and REACH Compliant: Ensures adherence to environmental and safety standards.
- Wide Voltage Range: Compatible with voltages from 208 to 690 VAC.
- High Amperage Rating: Supports up to 83 Amps.
- Transient Protection: Effective for single-phase drives, reducing voltage spikes and electrical noise.
- Epoxy Impregnation: Minimizes audible noise and enhances structural and moisture integrity.
- Compact Design: Optimized for space-saving installation without compromising performance.
- Global Compatibility: Designed to meet international standards, facilitating global shipping and usage.
- Versatile Mounting Options: Multiple mounting configurations to suit various installation needs.
- Motor Protection: Suitable for applications requiring protection for lower horsepower motors.
- Certifications: CE and UL certified, ensuring compliance with international safety and performance standards.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 83 A
- Inductance: 0.00017 H (0.17mH)
- Watt Loss: 22.3 W
- Horsepower Ratings:
- @ 240 VAC: 25 hp (3% Impedance), 30 hp (3% Impedance)
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 19 lbs
- Gross Weight: 19.2 lbs
