Description
The MTE RLW-006507 reactor is designed to provide efficient filtering and protection for industrial power systems. With a current rating of 65 amps and an inductance of 1.1mH, it effectively absorbs power line disturbances, ensuring smooth and reliable operation of equipment. This reactor is compliant with RoHS and REACH standards, prioritizing environmental sustainability and safety. Its open design allows for easy access and installation flexibility, making it suitable for various applications. The epoxy impregnation minimizes audible noise and enhances structural integrity, ensuring long-term performance. With approvals from CE and UL, this reactor meets international quality and safety standards.
Features
- RoHS and REACH Compliant: Meets environmental and safety standards.
- Wide Voltage Compatibility: Compatible with standard voltages from 208 to 690 VAC.
- Flexible Amperage Ratings: Supports ratings from 0.5 to 750 Amps.
- Transient Protection: Ideal for safeguarding single-phase drives against power line disturbances.
- Epoxy Impregnation: Minimizes audible noise and enhances structural integrity.
- Compact and Lightweight Design: Optimized for peak performance with reduced size and weight.
- Open Design: Provides easy access and flexibility in installation.
- Multiple Mounting Options: Offers versatility in installation to meet various needs.
- Global Design: Suitable for worldwide machine shipments, designed from a global perspective.
- Lower Horsepower Selection: Designed for smaller motor protection needs.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Current Rating: 65 A
- Inductance: 0.0011 H
- Watt Loss: 191 W
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 44 lbs
- Manufacturer Part Number: RLW-006507
- Item Number: RLW-006507
