Description
The MTE RLW-006503 reactor is part of the advanced RLW series, offering state-of-the-art filtering solutions to protect and enhance the performance of industrial power systems. With a current rating of 65 amps and an inductance of 0.38mH, this reactor is designed for applications needing robust transient protection. Its open design facilitates better heat dissipation and makes it suitable for environments where enclosure is not a necessity. The reactor is compliant with RoHS and REACH standards, ensuring it meets high environmental and safety standards.
Features
- RoHS and REACH Compliant: Ensures the product is environmentally friendly.
- Voltage Compatibility: Suitable for standard voltages ranging from 208 to 690 VAC.
- Transient Protection: Effective for single-phase drives and various power conversion units.
- Epoxy Impregnation: Reduces audible noise and enhances structural integrity and moisture resistance.
- Open Design: Allows for better heat dissipation in suitable environments.
- Compact and Lightweight: Designed for optimal performance with a smaller footprint.
- Multiple Mounting Options: Accommodates diverse machine building needs.
- Global Shipping Compatibility: Designed with a global perspective for international use.
- Approvals: CE, UL
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 65 A
- Inductance: 0.011 H
- Watt Loss: 14.3 W
- HP @ 240 VAC: 20 hp
- Impedance @ 240 VAC: 5 %
- HP @ 480 VAC: 40 hp, 50 hp
- Impedance @ 480 VAC: 3 %
- HP @ 600 VAC: 60 hp
- Impedance @ 600 VAC: 3 %
- Terminals: Terminal Block
- Mounting: Surface
- Manufacturer Part Number: RLW-006503
- Item Number: RLW-006503
- Ships Factory Direct: No
- Net Weight: 22 lbs
- Gross Weight: 22 lbs
- Approvals: CE, UL
Reviews
There are no reviews yet
