Description
The MTE RLW-006501 reactor is a robust and efficient line reactor designed to improve the performance and longevity of electrical equipment by mitigating power line disturbances. This reactor is part of MTE’s RLW series, which features state-of-the-art filtering solutions suitable for various power conversion units. With an inductance of 0.19mH and a current rating of 65 amps, this reactor is ideal for heavy-duty industrial applications. Its open construction provides flexibility in installation where an enclosure is not required.
Features
- RoHS and REACH Compliant: Complies with environmental and safety regulations regarding hazardous substances.
- Voltage Compatibility: Suitable for a wide range of voltages from 208 to 690 VAC.
- High Amperage Rating: Can handle up to 65 Amps, suitable for demanding applications.
- Transient Protection: Effective protection for single-phase drives against electrical noise and voltage spikes.
- Epoxy Impregnation: Reduces audible noise and enhances structural and moisture resistance.
- Compact and Lightweight Design: Offers optimal performance in a smaller, lighter package compared to other standard reactors.
- Multiple Mounting Options: Designed for flexible installation to meet various machine building requirements.
- Global Design: Conforms to international standards, facilitating global shipping and usage.
- Motor Protection: Appropriate for lower horsepower motor protection applications.
- Certifications: Approved by CE and UL, ensuring compliance with global safety and performance standards.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 65 A
- Inductance: 0.00019 H (0.19mH)
- Watt Loss: 9 W
- Horsepower Ratings:
- @ 240 VAC: 20 hp
- Impedance @ 240 VAC: 3%
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 18 lbs
- Gross Weight: 19.15 lbs
