Description
The MTE RLW-005501 reactor is a highly efficient line reactor designed to enhance the performance and longevity of electrical equipment by absorbing and mitigating power line disturbances. Part of the RLW series, this reactor offers state-of-the-art filtering solutions for various power conversion units, such as 4 or 6 pulse rectifiers. With an inductance of 0.27mH and a current rating of 55 amps, it is suitable for robust industrial applications. Its open construction allows for flexible installation options where enclosure is not a primary concern.
Features
- RoHS and REACH Compliant: Adheres to regulations restricting the use of hazardous materials.
- Wide Voltage Compatibility: Usable with standard voltages ranging from 208 to 690 VAC.
- High Amperage Capability: Handles up to 55 Amps, ideal for high-demand applications.
- Single-Phase Drive Protection: Provides transient protection for single-phase drives.
- Epoxy Impregnation: Enhances structural integrity, reduces audible noise, and improves moisture resistance.
- Compact and Lightweight Design: Delivers optimal performance in a smaller, lighter package compared to other reactors.
- Versatile Mounting Options: Designed for multiple mounting configurations to meet diverse machine building needs.
- International Standards Compliance: Suitable for global applications due to compliance with international standards.
- Motor Protection: Designed to offer lower horsepower selection for smaller motor protection requirements.
- Certifications: Certified by CE and UL, ensuring adherence to global safety and performance standards.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 55 A
- Inductance: 0.00027 H (0.27mH)
- Watt Loss: 10.9 W
- Horsepower Ratings:
- @ 240 VAC: 15 hp
- Impedance @ 240 VAC: 3%
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 18 lbs
- Gross Weight: 18.1 lbs
