Description
The MTE RLW-004607 reactor is part of the RLW series, specifically designed to enhance the performance and longevity of electronic equipment by mitigating power line disturbances. It features an inductance of 1.6mH and a current rating of 46A, making it suitable for various industrial applications.
Features
- RoHS and REACH Compliant: Meets international environmental and safety standards.
- Wide Voltage Range: Compatible with standard voltages from 208 to 690 VAC.
- Amperage Ratings: Suitable for applications with current ratings from 0.5 to 750 Amps.
- Single-Phase Drive Protection: Provides transient protection for single-phase drives.
- Epoxy Impregnation: Minimizes audible noise and enhances structural and moisture integrity.
- Compact and Lightweight Design: Optimized for peak performance with a smaller size and lighter weight compared to standard reactors.
- Multiple Mounting Options: Designed to accommodate various machine building needs.
- Global Compatibility: Suitable for equipment intended for international markets.
- Lower Horsepower Selection: Ideal for protecting smaller motors.
Specifications
- Manufacturer: MTE
- Model: RLW-004607
- Series: RLW
- Phase: 3
- Enclosed Unit: No
- Current Rating: 46 A
- Inductance: 1.6mH (0.0016 H)
- Watt Loss: 250 W
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Comments: At 690 VAC 50 Hz – 50 HP/4% Impedance
- Net Weight: 29 lbs
