Description
The MTE RLW-004605 reactor is a highly efficient and reliable line reactor designed to enhance the performance and longevity of electrical equipment by absorbing power line disturbances. It features an inductance of 0.98mH and a current rating of 46 amps, making it suitable for a range of industrial applications. This model is open-type, offering flexibility in installation where an enclosure is not required.
Features
- RoHS and REACH Compliant: Meets environmental and safety standards for hazardous substances and chemicals.
- Wide Voltage Compatibility: Suitable for use with voltages from 208 to 690 VAC.
- High Amperage Rating: Supports up to 46 Amps.
- Transient Protection: Effective for protecting single-phase drives from electrical noise and voltage spikes.
- Epoxy Impregnation: Reduces audible noise and enhances structural and moisture integrity.
- Compact and Lightweight: Designed for optimal performance in a smaller, more manageable size.
- Multiple Mounting Options: Allows for various installation configurations to suit different machine building needs.
- Global Design: Adheres to international standards, making it suitable for worldwide shipping and use.
- Motor Protection: Suitable for lower horsepower motor applications requiring protection.
- Certifications: CE and UL approved, ensuring compliance with global safety and performance standards.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 46 A
- Inductance: 0.00098 H (0.98mH)
- Watt Loss: 6.9 W
- Horsepower Ratings:
- @ 480 VAC: 25 hp, 30 hp
- @ 600 VAC: 40 hp
- Impedance:
- @ 480 VAC: 5%
- @ 600 VAC: 5%
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 24 lbs
- Gross Weight: 24 lbs
