Description
The MTE RLW-004601 reactor is engineered to provide robust protection and enhance the performance of electrical equipment by absorbing power line disturbances. With a current rating of 46 amps and an inductance of 0.3mH, this reactor is optimized for medium current applications. The open design ensures efficient heat dissipation, making it suitable for environments where enclosure protection is not a primary concern.
Features
- RoHS and REACH Compliant: Ensures the reactor is environmentally friendly by adhering to stringent regulations on hazardous substances.
- Wide Voltage Compatibility: Can operate across standard voltage ranges from 208 to 690 VAC, making it versatile for various applications.
- Broad Amperage Range: Suitable for applications requiring current ratings from 0.5 to 750 amps.
- Transient Protection: Ideal for single-phase drives, providing effective protection against transient voltage spikes.
- Epoxy Impregnation: Reduces audible noise and improves structural integrity and moisture resistance.
- Compact and Lightweight Design: Offers a state-of-the-art solution that is smaller and lighter than traditional reactors.
- Multiple Mounting Options: Designed to accommodate various mounting configurations for ease of installation.
- Global Design: Meets international standards, facilitating global deployment.
- Motor Protection: Suitable for protecting motors with lower horsepower requirements.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 46 A
- Inductance: 0.3 mH
- Watt Loss: 77 W
- Horsepower Ratings:
- @ 240 VAC: 12.5 hp
- Impedance:
- @ 240 VAC: 3%
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 13 lbs
- Gross Weight: 17.26 lbs
