Description
The MTE RLW-003503 reactor is designed to enhance the reliability and longevity of electrical equipment by mitigating power line disturbances. It is engineered for applications requiring a current rating of 35 amps and an inductance of 0.71mH. This open unit is ideal for environments where an enclosed reactor is not necessary, providing efficient transient protection and noise reduction.
Features
- RoHS and REACH Compliant: Ensures environmental and safety compliance.
- Wide Voltage Compatibility: Suitable for voltage ranges from 208 to 690 VAC, providing flexibility across various applications.
- Broad Amperage Range: Suitable for applications with current ratings from 0.5 to 750 amps.
- Transient Protection: Protects single-phase drives from voltage spikes.
- Epoxy Impregnation: Reduces audible noise and enhances structural integrity and moisture resistance.
- Compact and Lightweight Design: Modern, space-saving design compared to traditional reactors.
- Multiple Mounting Options: Easy installation with various mounting configurations.
- Global Design: Meets international standards for global deployment.
- Motor Protection: Suitable for protecting motors with lower horsepower requirements.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No
- Current Rating: 35 A
- Inductance: 0.71 mH
- Watt Loss: 4.8 W
- Horsepower Ratings:
- @ 240 VAC: 10 hp
- @ 480 VAC: 25 hp
- Impedance:
- @ 240 VAC: 5%
- @ 480 VAC: 3%
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 13 lbs
- Gross Weight: 14.3 lbs
