Description
The RLW-003501 reactor from MTE is part of the RLW series, known for its robust design and effective transient protection capabilities. It is ideal for industrial applications where electrical equipment requires protection from voltage spikes and disturbances.
Features
- RoHS and REACH Compliant: Complies with environmental and safety standards.
- Voltage Compatibility: Supports standard voltages from 208 to 690 VAC.
- Amperage Ratings: Wide range from 0.5 to 750 Amps, suitable for various applications.
- Transient Protection: Protects single-phase drives from power line disturbances.
- Crossover Tables: Available for compatibility with other standard reactors.
- Epoxy Impregnation: Reduces audible noise and enhances structural and moisture integrity.
- Compact Design: Lightweight and compact compared to traditional reactors, optimizing space and installation flexibility.
- Multiple Mounting Options: Allows for versatile installation to meet different machine building needs.
- Global Application: Designed for global use, facilitating shipment and compliance with international standards.
- Motor Protection: Suitable for smaller motor protection needs.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No (Open)
- Current Rating: 35 A
- Inductance: 0.00035 H (0.35 mH)
- Watt Loss: 68.6 W
- Impedance @ 208 VAC:
- 10 HP with 3% impedance
- 12.5 HP with 5% impedance
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 10 lbs
- Gross Weight: 10.05 lbs
