Description
The RLW-002801 reactor is part of MTE’s RLW series, known for its advanced filtering capabilities and compact design. It is specifically engineered to enhance equipment reliability by absorbing power line disturbances and minimizing transient effects.
Features
- RoHS and REACH Compliant: Complies with environmental and safety standards.
- Voltage Compatibility: Supports standard voltages from 208 to 690 VAC.
- Amperage Ratings: Covers a wide range from 0.5 to 750 Amps, suitable for various industrial applications.
- Transient Protection: Designed to protect single-phase drives from voltage spikes and disturbances.
- Crossover Tables: Available for compatibility with other standard reactors.
- Epoxy Impregnation: Reduces audible noise, enhances structural integrity, and improves resistance to moisture.
- Compact and Lightweight: Designed for space efficiency and ease of installation, reducing footprint and weight compared to traditional reactors.
- Versatile Mounting Options: Offers flexibility in installation to meet specific machine building requirements.
- Global Design: Facilitates worldwide deployment, meeting international standards.
- Motor Protection: Suitable for applications requiring lower horsepower protection.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No (Open)
- Current Rating: 28 A
- Inductance: 0.092 H (92 mH)
- Watt Loss: 5.4 W
- Impedance @ 240 VAC: 3%
- HP @ 240 VAC: 7.5 hp, 10 hp
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 5.1 lbs
- Gross Weight: 6.15 lbs
