Description
The RLW-002101 reactor is part of MTE’s RLW series, known for its advanced filtering capabilities and compact design. It is specifically engineered to absorb power line disturbances effectively, thereby minimizing transient effects and ensuring stable operation of equipment.
Features
- RoHS and REACH Compliant: Adheres to environmental and safety standards.
- Voltage Compatibility: Supports standard voltages ranging from 208 to 690 VAC.
- Wide Amperage Range: Rated for currents from 0.5 to 750 Amps, suitable for diverse industrial applications.
- Transient Protection: Ideal for safeguarding single-phase drives against voltage spikes and disturbances.
- Crossover Tables: Available to facilitate compatibility with other standard reactors.
- Epoxy Impregnation: Reduces audible noise, enhances structural integrity, and improves resistance to moisture.
- Compact and Lightweight: Designed for space efficiency and ease of installation, reducing footprint and weight compared to conventional reactors.
- Flexible Mounting Options: Provides versatility in installation to meet specific machine building requirements.
- Global Design: Enables deployment worldwide, meeting international standards.
- Motor Protection: Particularly suited for applications requiring lower horsepower protection.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No (Open)
- Current Rating: 21 A
- Inductance: 0.00053 H (0.53 mH)
- Watt Loss: 38.3 W
- Impedance @ 240 VAC: 3%
- HP @ 240 VAC: 5.5 hp, 7.5 hp
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 4.2 lbs
- Gross Weight: 5.35 lbs
