Description
The RLW-001406 reactor from MTE belongs to the RLW series, which is known for its robust design and effective transient protection capabilities. It is designed for use in various industrial applications where electrical equipment is susceptible to voltage fluctuations and disturbances.
Features
- RoHS and REACH Compliant: Meets environmental and safety standards.
- Voltage Compatibility: Supports standard voltages ranging from 208 to 690 VAC.
- Amperage Ratings: Covers a wide range from 0.5 to 750 Amps, suitable for diverse applications.
- Transient Protection: Protects single-phase drives from voltage spikes and line disturbances.
- Crossover Tables: Available for compatibility with other standard reactors.
- Epoxy Impregnation: Reduces audible noise and enhances structural and moisture integrity.
- Compact Design: Lightweight and compact compared to traditional reactors, optimizing space and installation flexibility.
- Multiple Mounting Options: Allows for versatile installation to accommodate different machine building needs.
- Global Application: Designed for global use, facilitating shipment and compliance with international standards.
- Motor Protection: Tailored for smaller motor protection requirements.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No (Open)
- Current Rating: 14 A
- Inductance: 0.0033 H (3.3 mH)
- Watt Loss: 66 W
- HP @ 600 VAC: 10 hp
- Impedance @ 600 VAC: 5 %
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 9.4 lbs
- Gross Weight: 10.2 lbs
