Description
The RLW-001405 reactor is part of MTE’s RLW series, known for its advanced filtering capabilities and compact design. It is designed to optimize the performance and longevity of electrical equipment by mitigating power line disturbances effectively.
Features
- RoHS and REACH Compliant: Adheres to environmental and safety standards.
- Voltage Compatibility: Supports standard voltages from 208 to 690 VAC.
- Amperage Ratings: Covers a range from 0.5 to 750 Amps, suitable for various industrial applications.
- Transient Protection: Ideal for protecting single-phase drives against voltage spikes and disturbances.
- Crossover Tables: Available to facilitate compatibility with other standard reactors.
- Epoxy Impregnation: Reduces audible noise, enhances structural integrity, and improves resistance to moisture.
- Compact and Lightweight: Designed for space efficiency and ease of installation compared to traditional reactors.
- Versatile Mounting Options: Allows for flexible installation to meet specific machine building requirements.
- Global Design: Enables deployment worldwide, compliant with international standards.
- Motor Protection: Particularly suitable for applications requiring lower horsepower protection needs.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No (Open)
- Current Rating: 14 A
- Inductance: 0.0026 H (2.6 mH)
- Watt Loss: 60.6 W
- Impedance @ 480 VAC: 5%
- HP @ 480 VAC: 10 hp
- Impedance @ 600 VAC: 3%
- HP @ 600 VAC: 10 hp
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 7.1 lbs
- Gross Weight: 7.8 lbs
