Description
The RLW-001403 reactor is an open-type three-phase reactor designed to enhance the reliability and performance of industrial equipment by reducing power line disturbances and electrical noise.
Features
- RoHS and REACH Compliant: Meets environmental and safety standards.
- Wide Voltage Compatibility: Supports standard voltages from 208 to 690 VAC.
- Amperage Ratings: Suitable for currents ranging from 0.5 to 750 Amps.
- Transient Protection: Effective for single-phase drives, protecting against voltage spikes and electrical disturbances.
- Crossover Tables: Available for compatibility with various standard reactors.
- Epoxy Impregnation: Minimizes audible noise, enhances structural integrity, and improves resistance to moisture.
- Compact and Lightweight: Designed for space efficiency and ease of installation, with reduced size and weight compared to traditional reactors.
- Versatile Mounting Options: Offers flexibility in installation to meet specific machine building requirements.
- Global Design: Designed for international use, meeting global standards for reliability and performance.
- Motor Protection: Suitable for applications requiring lower horsepower protection.
Specifications
- Manufacturer: MTE
- Product Series: RLW
- Family Series: MTE Line Reactors, RLW Series
- Phase: 3
- Enclosed Unit: No (Open)
- Current Rating: 14 A
- Inductance: 0.0016 H (1.600 mH)
- Watt Loss: 48.2 W
- Impedance @ 480 VAC: 3%
- HP @ 480 VAC: 10 hp
- Terminals: Terminal Block
- Mounting: Surface
- Approvals: CE, UL
- Net Weight: 4.3 lbs
- Gross Weight: 5.25 lbs
